Take Down and Alley Lights

Alley Lights

Located at the ends of the light bar to provide light to the side of the vehicle.

Stationary Lamps/Takedown Lights

A stationary assembly used for ArrowStik ashing, takedown, and/or work light applications.

The lamps used for either application are either MR11 Halogen or LED. Reference Figure 8.

MR-11 (Halogen)

LED

FIGURE 8

FIGURE 7

Jumpers shown in

default positions

1 2 ... 9 10 11 12 13 14 15 16 17 18
